VSI Vertical Shaft Impact Crusher

Type: Tertiary Crusher
Input Size: 0-50 mm
Capacity: 30-600 TPH
Processed Materials: Iron ore, copper ore, gold and silver ore, zinc ore, manganese ore, limestone, granite, basalt, river stone, coal gangue,quartz,etc.
Applications: Mechanism sand, bituminous concrete, metal mine, aggregates shaping, construction, etc.

+86-13523011655



  • Features
  • Technical Data
  • Application
  • Services
    1. Advanced double pump oil lubrication system minimizes the maintenance frequency.
    2. High precision roller bearing, smooth main unit running, and long service time.
    3. Hydraulic lift cap, easy and convenient replacement and maintenance.
    4. Over vibration alarm system.
    5. Special dustproof seal system, outside powder is prevented from entering nozzles .
    6. Unique feeding method, change between central feeding and central feeding with cascade feeding makes rock on rock and rock on iron possible, both crushing and shaping are achieved.
    7. Particular material throw head design and reasonable material selection prolongs the service time.
  • Model Max Feed Size
    (mm)    		 Rotor Speed
    (r/min)    		 Capacity
    (t/h)    		 Motor
    (kw)    		 Dimensions
    (mm)    		 Weight
    (kg)
    VSI-3000 45(70) 1760-2210 30-60 55-90 30 ≤5555
    VSI-4000 55(70) 1550-1940 50-90 110-150 55 ≤7020
    VSI-5000 65(80) 1330-1670 80-150 150-220 55-75 ≤11650
    VSI-6000 70(100) 1190-1490 120-250 220-320 90-110 ≤15100
    VSI-7000 70(100) 1050-1310 180-350 264-400 90-110 ≤17090
    VSI-8000 70(100) 1330-1670 250-380 320-440 90-110 ≤18495
    VSI-8000 I 80(120) 940-1170 320-600 440-630 110-132 ≤24610
  • 1. Center Feeding:

    Raw material falls down into feed hopper, then enters impellor through central entrance hole. It is accelerated in high-speed impellor, then is thrown out at speed of 60-75 m/s. When hitting impact plate, it is crushed. Final products come downwards though outlet.

    2. Ring Feeding:

    Raw material falls down into feed hopper, then through ring, it is devided into two parts by material-dividing plate. One enters into impellor through the center of material-dividing plate. The other falls down from outside of material-dividing plate. Material, which is thrown out by impellor at speed of 60-75m/s, hits material coming down from outside of material-dividing plate. In this way, material is crushed.


  •   Supply the most current design and technical expertise
      Supply parts sales and training service far beyond the initial sale
      Your profits with quality parts and expert service
